L Series Long Shaft Trolling Motor

Regular price $269.00 Sale

L Series Electric Trolling Motor | 3/4 View | Newport

L Series Electric Trolling Motor | Left 3/4 View | Newport

Newport L Series Electric Trolling Motor Side View

Newport L Series Electric Trolling Motor Back View

The L Series 24V long shaft trolling motor features a 40" adjustable shaft and 8 speeds for optimal control. Weighing only 23lbs, it's powerful, portable, and perfect for medium to large boats, excelling in both freshwater and saltwater.

LED battery meter

Extendable Handle

Freshwater & Saltwater

Shaft Length

LED battery meter

Extendable Handle

Freshwater & Saltwater

Shaft Length

Shaft Length
1300 W

PEAK POWER
66 MILES

MAX RANGE
6.5 MPH

TOP SPEED
30 HRS

Max Runtime
600 W

PEAK POWER
100 MI

MAX RANGE
+6 MPH

SPEEED
37.5 HRS

MAX RUN TIME
SHAFT LENGTH
Bluetooth Enabled
Newport App
IP65 Water Resistant
24.3 Lbs
12 V

VOLTAGE
50 Ah

Amp Hours
13.6 LBS

WEIGHT
14.6 VDC

Charger
Bluetooth Enabled
Newport App
Newport App
1300 W

PEAK POWER
66 MILES

MAX RANGE
6.5 MPH

TOP SPEED
30 HRS

MAX RUNTIME
12 v

Voltage
50 Ah

Amp Hours
30.2 LBS

WEIGHT
Shaft

Carbon Fiber
NT300

Compatible
Sit/Stand

Operation
Trolling Motor

Compatible
Vaccum

Insulated

L Series Long Shaft Trolling Motor

(50)

Regular price $269.00 Sale

With a fully adjustable 40-inch fiberglass composite shaft, this L Series 24 volt long shaft trolling motor is built to fit all transom mount boats such as sailboats, fishing skiffs, pontoon boats, and other medium to large size boats.

Size

62lb

86lb

30” Shaft Length

30 Days Money-Back Guarantee

Zip Code

Save

Invalid zip code

Add Accessories Bundle

$164.00

$194.00

Newport 12V 50Ah Deep Cycle Marine Battery

$129.00

Newport Smart Battery Box - 12V

$65.00

L Series

The motor's 8 speeds (5 forward speeds and 3 reverse) provide complete control for a smooth ride in any water condition. The trolling motor comes with a 3 blade propeller (10-inch diameter) for optimal performance and runs on any 12-volt Deep Cycle or Marine battery (not included). Two 12-volt Deep Cycle batteries connected in Series are required for the 24V 86lb thrust motor.

How far will you go?

Motor Range Estimator

Select from the dropdown options below to locate the type of battery and vessels you plan on using with the L Series Long Shaft Trolling Motor. Our motor range estimator module will provide you with the range (in miles), runtime (in hours), and efficiency (in watt hours).

Traveling Speeds

1 MPH

2 MPH

3 MPH

4 MPH

5 MPH

6 MPH

7 MPH

Range

distance calculation

Runtime

time calculation

Efficiency

WattHrs/Mile

THE NEWPORT DIFFERENCE

Power Your Adventures With Peace Of Mind

Say Goodbye To Hit-or-Miss Performance And Hello To Uninterrupted Fun On The Water With Our Advanced Technology

Adjustable & Versatile

A fully adjustable fiberglass composite shaft stands up to any conditions, and ensures compatibility with medium to large size boats.

40-inch adjustable fiberglass shaft
6” Telescoping handle
Large boat compatibility

Power & Portability

Despite its robust performance, this 24-volt trolling motor weighs only 23 pounds, striking an ideal balance between power and portability. It's designed to provide powerful thrust while remaining easy to transport and install.

24-volt, long shaft power
50/60A auto breaker
23 lb motor, lightweight & powerful

Comprehensive Speed Control

Equipped with 8 speeds (5 forward and 3 reverse) a 10-inch diameter three-blade propeller and an LED battery meter offers complete control and smooth performance in any water condition.

5 forward & 3 reverse speeds
10-inch, 3-blade propeller
5-point LED battery meter

Empowering Your Boating Experience

THE SPECS // AT A GLANCE

Unlocking the Potential of Newport Motors

Thrust Options: 62lb | 86lb
Shaft Length: 40"
Tiller/Handle: 6" Telescoping
Input Voltage: 12V DC (62lb) | 24V DC (86lb)
Weight:23lbs | 25lbs
External Battery:12V DC
Propeller: 3 Blade - Large
Motor:Brushed
Water Compatibility:Saltwater & Freshwater
Speeds:5 forward, 3 reverse speeds
Max Amp Draw:50A
Horsepower Equivalent:0.93HP | 1.5 HP

30 Days Money-Back Guarantee

the Newport difference

Discover the Superiority of Newport Motors

Compare Motor Models Below

Product

Propulsion Type

Purpose

Power

Shaft Length

Weight

Battery Meter

Stock Propeller

Motor

Max Amp Draw

Freshwater and Saltwater Compatibility

Battery Requirements

Mount

L Series Trolling Motor

Trolling Motor

Secondary Propulsion

62lbs & 86lbs

40"

23lbs & 25lbs

5-Point LED

3 Blade (Large)

Brushed

50 Amps

✓

12V Deep Cycle or 24V Deep Cyle

Standard Transom Mount

Pontoon Series

Trolling Motor

Secondary Propulsion

55 lbs & 86lbs

55"

23lbs & 25lbs

10-Point LED

3 Blade (Large)

Brushed

50 Amps

✓

12V Deep Cycle or 24V Deep Cyle

Standard Transom Mount

NV Series Trolling Motor

Trolling Motor

Secondary Propulsion

30", 36"

18lbs, 20lbs, 23lbs, 23lbs, 25lbs

5-Point LED

3 Blade (Standard)

Brushed

29A | 40A | 52A | 58A | 48A

✓

12V Deep Cycle or 24V Deep Cyle

Standard Transom Mount

NT300

Outboard Motor

Primary Propulsion

110lb Thrust (3.0 HP Equivalent)

24.6"

23.8lbs

Digital Battery Percentage & Voltage Display

2 Blade (NT300)

Brushless

37 Amps

✓

One 36V Deep Cycle

Standard Transom Mount

30 Days Money-Back Guarantee

tried and trusted

Take It From These Avid Anglers

Read Real Testimonials From Satisfied Customers

Find Answers to Your Questions

Frequently Asked Questions

What's In The Box?

L Series Trolling Motor (40" Shaft)
Propeller
3 Blade Propeller - Large
Propeller Installation Hardware
Drive-Pin, Washer, Tightening Nut and Spanner/Wrench
Circuit Breaker
60A (62lb) || 50A (86lb)
L Series Trolling Motor Owners Manual

OTHER ACCESSORIES NEEDED FOR OPERATION:
12V Deep Cycle or Marine Battery (Lead-Acid) rated at least 50 amp hour (ah). Amp hours will determine the run time of the motor.
86lb Motor requires 2 x 12V batteries connected in series (24V)
12V Battery Charger.
Owner's Manual

Download Owner's Manual
Why Do I Have 5 Reverse Speeds And 3 Forward?

See details here
How to Install Your Trolling Motor on a Transom

See details here
How Do I to Store Your Trolling Motor?

See details here
After Use Care For Trolling Motors

See details here
