1300W
Peak Power
66 Miles
Max Range
6.5 MPH
Top Speed
30 HRS
Max Run Time
Best Seller
NT300 Electric Outboard Motor
$1,199.99
description
Redefining power, the NT300 is a clean, quiet, 3 horsepower electric outboard motor in a compact, portable package. Available in two shaft lengths: Standard 24.6" or Long 29"
Zip Code
Invalid zip code
30 Day Money-Back Guarantee
30 Day Returns
what’s in the box?
NT300 Parts
Owner's Manual
Fast & Tracked Delivery
30 Day Returns
2-Year Warranty
Legendary Customer Service
Tech Specs
Unlocking the Potential of Newport
- Power: 1300W (3HP equivalent)
- Shaft Options: Standard 24.6" or Long 29"
- Input Voltage: 36V DC
- Amp Draw: 37 amps
- Motor Weight: Standard 23.8 lbs or Long 24.3 lbs
- External Battery: 36V DC 30 Ah minimum
- Propeller: 9.8" 2-blade composite propeller
- Trim/Tilt Angle: 0°, 7°, 14°, 21° / 70°
- Shaft Length: 24.60"
- Motor: Brushless DC motor
- Direct Drive: Yes
- Maintenance-Free: Yes
- Sound Level: 40 decibels (out of water)
- Length of lower motor: 9.25"
- Diameter of lower motor: 4.5"
Battery Meter
Digital Battery Percentage & Voltage Display
Shaft Length
Short 24.6"
Shaft Length
Long 29"
Propeller
9.8" 2-Blade Composite Propeller
- Power: 1300W (3HP equivalent)
- Shaft Options: Standard 24.6" or Long 29"
- Input Voltage: 36V DC
- Amp Draw: 37 amps
- Motor Weight: Standard 23.8 lbs or Long 24.3 lbs
- External Battery: 36V DC 30 Ah minimum
- Propeller: 9.8" 2-blade composite propeller
- Trim/Tilt Angle: 0°, 7°, 14°, 21° / 70°
- Shaft Length: 24.60"
- Motor: Brushless DC motor
- Direct Drive: Yes
- Maintenance-Free: Yes
- Sound Level: 40 decibels (out of water)
- Length of lower motor: 9.25"
- Diameter of lower motor: 4.5"
Discover the Superiority of Newport Motors
Compare Motor Models Below
Propulsion Type
Outboard Motor
Trolling Motor
Trolling Motor
Purpose
Primary Propulsion
Secondary Propulsion
Secondary Propulsion
Power
110lb Thrust (3.0 HP Equivalent)
55lb Thrust
(0.83 HP Equivalent)
62lb Thrust
(0.93 HP Equivalent)
Shaft Length
24.6"
30"
40"
Weight
23.8lbs
23lbs
23lbs
Battery Meter
Digital Battery Percentage & Voltage Display
5-Point LED
10-Point LED
Stock Propeller
2 Blade (NT300)
3 Blade (Standard)
3 Blade (Large)
Motor
Brushless
Brushed
Brushed
Max Amp Draw
37 Amps
52 Amps
50 Amps
Freshwater and Saltwater Compatibility
Battery Requirements
One 36V Deep Cycle
One 12V Deep Cycle
One 12V Deep Cycle
Mount
Standard Transom Mount
Standard
Transom Mount
Standard
Transom Mount
Frequently Asked Questions
You know how they say there’s no such thing as a dumb question? Well, they were wrong, but here are some common not-so-dumb ones
