1300W
Peak Power
66 Miles
Max Range
6.5 MPH
Top Speed
30 HRS
Max Runtime
New

NK300 HD Electric Kayak Motor

Outline star
Outline star
Outline star
Outline star
Outline star
Filled star
Filled star
Filled star
Filled star
Filled star
(97)
$1,499.99

Features

  • Fastest NK HD (3HP/1300W)
  • Reinforced steering/retract system
  • HD communication cable connectors
  • Brushless direct drive
  • Newport battery system compatibility
  • Compact anodized Ronstan® block
  • Cable strain relief mechanism
  • Conformal-coated electronics

30 Day Risk-Free Trial

Industry Leading Warranty

Talk To An Expert: 866-721-0002

1300W
Peak Power
66 Miles
Max Range
6.5 MPH
Top Speed
30 HRS
Max Runtime
Details

The NK HD Series represents the next generation of Newport’s flagship kayak motors. Built around a heavy-duty durability standard, the NK300 HD combines rugged composite materials, updated architecture for easy lifting and steering authority, precision bearings, overbuilt communication cable plugs for long-term reliability, a micro pulley system for low-profile stowage and mounting, a cable strain relief mechanism for longer cable life, and advanced conformal-coated internal electronics engineered for maximum reliability. Designed for hardcore kayak anglers, it delivers 1300W of reliable brushless direct-drive power with unmatched speed and thrust, plus a redesigned throttle curve for smoother acceleration and precision control. Tournament angler trusted and proven on the water, this motor was built to explore where others won’t.

what’s in the box?
  • NK300 HD motor
  • NK HD Steering Triangle
  • NK HD Retract Arm w/ Stainless Carabiner + Ronstan micro block
  • NK HD Communication Cable with oversized M12 connectors
  • NK HD Digital Speed Controller w/ Display
  • Four Bolt Aluminum Motor Mounting bracket
  • Height Adjustment Clamp
  • Reverse Control Line and Handle
  • Motor Lift Control Line and Handle
  • Emergency Stop Key
  • (2) Carabiner and pulley sets for rigging options
  • Additional nylon cord
  • Coated Stainless Steering Cable Kit (may not be compatible w/ every brand of kayak)
    Installation Kit
  • Hardware installation kit with required tools
  • BATTERY NOT INCLUDED
Warranty policy

2 Year Limited Warranty. See more details

Owner's Manual

Download Owner's Manual
[{"variant_id":"52599266705775" , "metafield_value":""}]

NK300 HD Electric Kayak Motor

$1,499.99

NK HD. Power That Doesn’t Quit.

Built Heavy Duty

Overbuilt steering and lift arm architecture holds up to hard use.

  • Reinforced composite lift arm and steering triangle
  • Optimized geometry reduces strain
  • Micro pulley system for low-profile stowage and mounting
  • Cable strain relief mechanism for longer cable life

HD Communication System

Overbuilt connectors for stable, long-term reliability.

  • Oversized communication cable connectors
  • Conformal-coated electronics engineered for maximum reliability
  • All-new advanced PCB design for motor, driver, and controller
  • Consistent power delivery with reduced long-term wear

Precision Bearing Drive

Precision-engineered components improve operation and longevity.

  • Smooth, intuitive control
  • Responsive power command
  • Brushless direct-drive power
  • Optimized throttle curve for smoother acceleration and precision control
Calculate
Reset Filters
Traveling Speeds
1 MPH
2 MPH
3 MPH
4 MPH
5 MPH
6 MPH
7 MPH
Range
distance calculation
distance calculation
distance calculation
distance calculation
distance calculation
distance calculation
distance calculation
Runtime
time calculation
time calculation
time calculation
time calculation
time calculation
time calculation
time calculation
Efficiency
WattHrs/Mile
WattHrs/Mile
WattHrs/Mile
WattHrs/Mile
WattHrs/Mile
WattHrs/Mile
WattHrs/Mile

Tech Specs

Unlocking the Potential of Newport

  • Power: 1300W (3HP equivalent)
  • Input Voltage: 36V DC
  • Amp Draw: 37 amps
  • Motor Weight: 25.5 lbs
  • External Battery: 36V DC 30 Ah minimum
  • Propeller: 9.8" 2-blade composite propeller
  • Trim/Tilt Angle: 0°, 7°, 14°, 21° / 70°
  • Shaft Length: 21.7"
  • Motor: Brushless DC motor
  • Direct Drive: Yes
  • Maintenance-Free: Yes
  • Sound Level: 40 decibels (out of water)
  • Length of lower motor: 9.25"
  • Diameter of lower motor: 4.5"
Heavy Duty Steering Triangle
Reinforced for structural strength
HD Retract Arm
With micro pulley, reduces lifting strain
Precision Direct Drive
Smooth bearings & protected electronics
NK HD Connector
Secure, long-lasting connection
  • Power: 1300W (3HP equivalent)
  • Input Voltage: 36V DC
  • Amp Draw: 37 amps
  • Motor Weight: 25.5 lbs
  • External Battery: 36V DC 30 Ah minimum
  • Propeller: 9.8" 2-blade composite propeller
  • Trim/Tilt Angle: 0°, 7°, 14°, 21° / 70°
  • Shaft Length: 21.7"
  • Motor: Brushless DC motor
  • Direct Drive: Yes
  • Maintenance-Free: Yes
  • Sound Level: 40 decibels (out of water)
  • Length of lower motor: 9.25"
  • Diameter of lower motor: 4.5"

Discover the Superiority of Newport Motors

Compare Motor Models Below

Propulsion Type
Outboard Kayak Motor
Outboard Kayak Motor
Trolling Motor
Purpose
Primary Propulsion
Primary Propulsion
Secondary Propulsion
Power
110lb Thrust
(3 HP Equivalent)
110lb Thrust
(3 HP Equivalent)
55lb Thrust
(0.83 HP Equivalent)
Shaft Length
21.7"
21.7"
30"
Weight
25.5lbs
25.5lbs
23lbs
Battery Meter
Digital Battery Precentage & Voltage Display
Digital Battery Precentage & Voltage Display
5-Point LED
Stock Propeller
2 Blade (NK300)
2 Blade (NK300)
3 Blade (Standard)
Motor
Brushless
Brushless
Brushed
Max Amp Draw
37 AMPS
37 AMPS
52 Amps
NK HD Retract Arm
-
-
NK HD Steering Triangle
-
-
Freshwater and Saltwater Compatibility
Battery Requirements
(1) 36V LiFeP04
(1) 36V LiFeP04
(1) 12V Deep Cycle
Mount
4 Bolt Pattern
4 Bolt Pattern
Standard
Transom Mount

Frequently Asked Questions

You know how they say there’s no such thing as a dumb question? Well, they were wrong, but here are some common not-so-dumb ones

Contact us

What is the NK HD Series?

The NK HD Series is the next generation of Newport kayak motors. It is built around a Heavy Duty standard with upgraded steering, retract, and connection components integrated as standard equipment. It is designed specifically for kayak anglers who spend long days on the water and expect their gear to keep up.

What does “HD” mean?

HD stands for Heavy Duty. It reflects a stronger, more durable motor platform designed for real-world kayak fishing use, transport, and repeated time on the water.

Is the NK HD an upgrade or a new product?

The NK HD Series is a new product generation. It replaces previous NK models and establishes the new baseline for Newport kayak motors moving forward.

What’s different compared to previous NK motors?

The NK HD Series features an upgraded steering system, a redesigned retract arm, and a Heavy Duty communication connector built directly into the motor. These changes are focused on durability, confidence, and long-term use rather than adding new complexity.

Is the NK HD suitable for saltwater use?

Yes. The NK HD Series is built for both freshwater and saltwater kayak fishing.

Does the NK HD require a different installation process?

No. Installation is straightforward and similar to previous NK motors. Updated installation guides are provided with the motor.
