600W
Peak Power
100 Miles
Max Range
+6 MPH
Top Speed
37.5 HRS
Max Run Time
NK180PRO Electric Kayak Motor
$1,199.99
description
Introducing the Newport NK180PRO Kayak Motor: Redefine your angling experience with unrivaled speed, whisper-quiet precision, and optimized efficiency. Elevate every journey on the water with the game-changing NK180PRO, setting a new standard for performance and control.
Zip Code
Invalid zip code
30 Day Money-Back Guarantee
30 Day Returns
what’s in the box?
NK180PRO parts
Owner's Manual
Fast & Tracked Delivery
30 Day Returns
2-Year Warranty
Legendary Customer Service
Tech Specs
Unlocking the Potential of Newport
- POWER:600W (1.8 HP EQUIVALENT)
- INPUT VOLTAGE:24V
- AMP DRAW:25 AMPS
- MOTOR WEIGHT: 14.3lbs
- Shaft Length:21.7"
- EXTERNAL BATTERY:YES
- PROPELLER:7.5” Diameter
- TRIM/TILT ANGLE:10°, 20°, 30°
- MOTOR:BRUSHLESS DC MOTOR
- DIRECT DRIVE:YES
- MAINTENANCE-FREE:YES
- LOWER MOTOR LENGTH:8.7"
- LOWER MOTOR SIZE:4"
Trim/Tilt Angle
10°, 20°, 30°
Shaft Length
21.7"
Propeller
7.5” 2 Blade
- POWER:600W (1.8 HP EQUIVALENT)
- INPUT VOLTAGE:24V
- AMP DRAW:25 AMPS
- MOTOR WEIGHT: 14.3lbs
- Shaft Length:21.7"
- EXTERNAL BATTERY:YES
- PROPELLER:7.5” Diameter
- TRIM/TILT ANGLE:10°, 20°, 30°
- MOTOR:BRUSHLESS DC MOTOR
- DIRECT DRIVE:YES
- MAINTENANCE-FREE:YES
- LOWER MOTOR LENGTH:8.7"
- LOWER MOTOR SIZE:4"
Discover the Superiority of Newport Motors
Compare Motor Models Below
Propulsion Type
Outboard Motor
Outboard Kayak Motor
Trolling Motor
Trolling Motor
Purpose
Primary Propulsion
Primary Propulsion
Secondary Propulsion
Secondary Propulsion
Power
65lb Thrust
(1.8 HP Equivalent)
60lb Thrust
(1.8 HP Equivalent)
36lb Thrust
(0.48 HP Equivalent)
55lb Thrust
(0.83 HP Equivalent)
Shaft Length
21.7"
21"
24"
30"
Weight
14.3lbs
14.3lbs
18lbs
23lbs
Battery Meter
Digital Battery Percentage & Voltage Display
Digital Battery Percentage & Voltage Display
5-Point LED
5-Point LED
Stock Propeller
2 Blade (NK180PRO)
2 Blade (NK180)
2 Blade (Standard)
3 Blade (Standard)
Motor
Brushless
Brushless
Brushed
Brushed
Max Amp Draw
25 Amps
25 Amps
29 Amps
52 Amps
Freshwater and Saltwater Compatibility
Battery Requirements
One 24V LiFeP04
One 24V LiFeP04
One 12V Deep Cycle
One 12V Deep Cycle
Mount
4 Bolt Pattern
4 Bolt Pattern
Standard
Transom Mount
Standard
Transom Mount
Frequently Asked Questions
You know how they say there’s no such thing as a dumb question? Well, they were wrong, but here are some common not-so-dumb ones
